A Progressive Cavity Pump (PC pump) is a positive displacement pump that uses a single helical rotor moving within a double-threaded, elastomeric stator to create a series of small cavities. This design allows for the smooth, pulsation-free movement of fluid.

A Progressive Cavity Pump operates on the principle of positive displacement. The helical rotor, turning within the stator, creates a series of sealed cavities that move the fluid from the inlet to the outlet, providing a constant and smooth flow.

PC pumps are versatile and are suitable for pumping fluids with varying viscosities,  solids content, and shear sensitivity.  Progressive cavity pumps find applications across diverse industries such as:

• Environment - Water and Wastewater Treatment
• Sugar
• Paper
• Explosives
• Marine
• Oil & Gas
• Mining
• Ceramics
• Man Made Fibres
• Constructions
• Wine & Beverages
• Chemicals
• Paint
• Edible Oil
• Food
• Pharma
• Cosmetics
• Agriculture
• Cattle Feed

The unique design of PC pumps, with the helical rotor and elastomeric stator, allows them to handle highly viscous fluids by creating a  continuous seal and providing a gentle, low-shear pumping action.

 Progressive Cavity Pumps are capable of handling fluids with suspended solids. The design minimizes the risk of damaging or shearing solids, making them suitable for applications where gentle handling of particles is crucial.

 PC pumps excel in sludge transfer applications due to their ability to handle high-viscosity sludge efficiently. The positive displacement action ensures consistent and reliable sludge transfer.

 Yes, Progressive Cavity Pumps are generally self-priming, which means they have the ability to create a suction lift and draw fluid into the pump without the need for external priming.

 Yes, Progressive Cavity Pumps are known for their gentle handling of shear-sensitive fluids. The design minimizes shear forces, making them suitable for delicate substances.

  The flow rate of a PC pump can be controlled by adjusting the pump speed. Variable frequency drives (VFDs) and manual mechanical speed variators are commonly used to vary the pump speed, allowing for precise control of the flow rate.

  Yes, Progressive Cavity Pumps are reversible, meaning they can pump in both directions. This feature enhances their versatility in various applications.

  Regular maintenance includes inspecting and replacing the stator and rotor as needed, monitoring the condition of seals, and checking alignment. Maintenance intervals depend on factors such as pump usage and the pumped fluid.

 Yes, Progressive Cavity Pumps are well-suited for handling abrasive fluids. The robust design and the use of wear-resistant materials make them effective in applications where abrasion is a concern.

  The temperature range depends on the materials of construction. Standard  PC pumps can handle temperatures up to 200°C (392°F), while specialized versions with high-temperature materials can handle even higher temperatures.

 Progressive Cavity Pumps are well-suited for fluids with a wide range of viscosities. As viscosity increases, the positive displacement action remains effective, allowing the pump to handle thicker fluids efficiently.

  Yes, there are sanitary-grade Progressive Cavity Pumps designed for applications in the food, pharmaceutical, and other industries where hygiene and cleanliness are critical.

   Yes, Progressive Cavity Pumps can be constructed with materials that resist corrosion, making them suitable for pumping corrosive fluids in chemical and industrial applications.

   Progressive Cavity Pumps generally have low NPSH requirements, meaning they can operate effectively with low suction pressure. This feature makes them suitable for applications with limited available NPSH.

 Sizing considerations include the desired flow rate, pressure requirements, viscosity, and characteristics of the pumped fluid.

 Yes, Progressive Cavity Pumps can handle fluids with entrained air or gases. The pump's design minimizes cavitation, making it suitable for applications with aerated fluids.

  Safety considerations include proper installation, alignment, and regular maintenance. It's important to follow manufacturer guidelines,  especially when handling hazardous materials or operating in potentially explosive atmospheres.
