METERING PUMP

Pumping Principle

 A progressive cavity pump is a type of positive displacement pump and is also known as an eccentric screw pump or Single screw Pump or helical rotor pump.


The progressive cavity pump normally consists of a helical rotor and a twin helix stator. The rotor seals tightly against the stator as it rotates, forming a set of fixed-size cavities in between. The cavities move axially when the rotor is rotated but their shape or volume does not change.

Advantages

Positive Displacement Pumping

  • .The net flow amount has minimal variation as the total displacement is equal. This design results in a flow with little to no pulsation.


Low Shearing

  •  The product moves gently through the pump via a cavity and is confined to the sealing line.


Self-priming

  • This pump is known for its excellent self-priming capability.


Low NPSHR

  •   Smooth and laminar flow even at critical suction conditions, lifting capability upto 9meters.


Quite Operation

  •  Typically the pump does not generate any noise, the loudest component of the pumping system is the motor fan OR prime mover arrangement.


Viscosity Handling

  •   Can handle viscosity from water-like liquid to highly viscous applications.


Duty Range

  • Flow                                                  150 M3/Hr  (660 GPM)
  • Pressure range                               24 Bar  (340 Psi)
  • Temperature                                   150 °C   (302 °F)
  • Viscosity                                          Upto 125,000 cSt
  • Solid Handling                                Upto 10%

Industries

  • Environment - Water and Wastewater Treatment
  • Sugar
  • Paper
  • Explosives
  • Marine
  • Oil & Gas
  • Mining
  • Ceramics
  • Man Made Fibre
  • Constructions
  • Wine & Beverages
  • Chemicals
  • Paint
  • Edible Oil
  • Food
  • Pharma
  • Cosmetics
  • Agriculture
  • Cattle Feed
